Specifications
|
Model |
XLf 220 A |
|
Speaker Size |
Dual 8" |
|
Max. Output Power |
550W |
| RMS Output Power |
220W |
|
Built-in Amplifier Type |
Class AB |
|
Impedance |
(2+2 Ω)x2 |
| Voice Coil Type | Dual Voice Coil |
|
Frequency Response |
30Hz-150Hz |
|
S/N Ratio |
91dB |
|
Low Pass Filter |
50Hz-100Hz |
|
Input Sensitivity |
RCA input 82mV/Speaker input 0.8V |
| Working Voltage | 14.4V(10-16V) |
|
Phase Switch |
0°/180° |
| Auto Turn ON/OFF | High-level input only |
| Fuse Rating |
15A |
| Gain | 200mV-6V |
|
Cone Material |
Aluminum |
| Magnet Type |
Ferrite |
|
Enclosure Material |
Die-cast Alumium |
| Dimensions | 504x340x85mm |
| Net Weight | 5kg |
